Cisco ASR 1000 Series Software Configuration Guide

and enter interface ATM VC configuration mode, perform the following procedure beginning in global
configuration mode:
SUMMARY STEPS
1.
Router(config)# interface atm slot/subslot/port.subinterface
2.
Router(config-if)# ip address address mask
3.
Router(config-if)# atm tx-latency milliseconds
4.
Router(config-if)# pvc [name ] vpi /vci
5.
Router(config-if-atm-vc)# protocol protocol {protocol-address | inarp} [[no] broadcast]
6.
Router(config-if-atm-vc)# inarp minutes
7.
Router(config-if-atm-vc)# encapsulation {aal5mux protocol | aal5nlpid| aal5snap}
8.
Router(config-if-atm-vc)# tx-limit buffers
9.
Router(config-if-atm-vc)# end
DETAILED STEPS
PurposeCommand or Action
Enters subinterface configuration mode pertaining to the specified port on the ATM
SPA, where:
Router(config)# interface atm
slot/subslot/port.subinterface
Step 1
• slot —Specifies the chassis slot number in the Cisco ASR 1000 Series Router
where the SIP is installed.
• subslot —Specifies the secondary slot of the SIP where the SPA is installed.
• port —Specifies the number of the individual interface port on a SPA.
• subinterface —Specifies the number of the subinterface.
Assigns the specified IP address and subnet mask to the interface or subinterface.Router(config-if)# ip address
address mask
Step 2
(Optional) Configures the default transmit latency for VCs on this ATM SPA interface.
The valid range for milliseconds is from 1 to 200, with a default of 100 milliseconds.
Router(config-if)# atm
tx-latency milliseconds
Step 3
Configures a new ATM PVC by assigning its VPI/VCI numbers and enters ATM VC
configuration mode. The valid values for vpi /vci are:
Router(config-if)# pvc [name ]
vpi /vci
Step 4
• name —(Optional) An arbitrary string that identifies this PVC.
• vpi —Specifies the VPI ID. The valid range is 0 to 255.
• vci —Specifies the VCI ID. The valid range is 32 to 65535. Values 1 to 31 are
reserved and should not be used, except for 5 for the QSAAL PVC and 16 for the
ILMI PVC. ILMI is unsupported on the Cisco ASR 1000 Series Aggregation
Services Routers.
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 67
Configuring the ATM SPAs
Creating a Permanent Virtual Circuit
