Cisco ASR 1000 Series Software Configuration Guide

CHAPTER 19
Configuring the 1-Port Channelized OC-3/STM-1
SPA and 1-Port Channelized OC-12/STM-4 SPA
This chapter provides information about configuring the 1-Port Channelized OC-3/STM-1 SPA and the
1-Port Channelized OC-12/STM-4 SPA on the Cisco ASR 1000 Series Aggregation Services Routers.
•
Restrictions for Configuring the 1-Port Channelized OC-12/STM-4 SPA, page 291
•
Configuration Tasks, page 291
•
Verifying Interface Configuration, page 318
•
Configuration Examples, page 320
Restrictions for Configuring the 1-Port Channelized OC-12/STM-4
SPA
This chapter contains information for configuring two models of the channelized SPAs on the Cisco ASR
1000 Series Aggregation Services Routers, but some features are not yet supported on both models.
Consider the following restrictions when configuring the 1-Port Channelized OC-12/STM-4 SPA on the Cisco
ASR 1000 Series Aggregation Services Routers in Cisco IOS XE Release 2.6:
•
Multilink Frame Relay (MLFR) is not supported.
•
A maximum of 2000 NxDS0 channels are supported.
APS is not supported on Channelized OC-x SPA.Note
Configuration Tasks
This section describes how to configure the 1-Port Channelized OC-3/STM-1 SPA and 1-Port Channelized
OC-12/STM-4 SPA on the Cisco ASR 1000 Series Router, including required and optional configurations.
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 291
