Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
• 3—Connects a T3 controller to an Adtran T3SU 300. Bandwidth range is
from 75 to 44210 kbps.
• 4—Connects a T3 controller to a Verilink HDM 2182. Bandwidth range is
from 1500 to 44210 kbps.
Specifies the maximum allowable bandwidth.Router(config-if)# dsu bandwidth
kbps
Step 4
• kbps—Bandwidth range is from 1 to 44210 kbps.
Verifying DSU Mode
Use the show controllers serial command to display the DSU mode of the controller:
Router# show controllers serial
Serial2/1/0 -
Framing is c-bit, Clock Source is Internal
Bandwidth limit is 44210, DSU mode 0, Cable length is 10
rx FEBE since last clear counter 0, since reset 0
Data in current interval (0 seconds elapsed):
0 Line Code Violations, 0 P-bit Coding Violation
0 C-bit Coding Violation
0 P-bit Err Secs, 0 P-bit Sev Err Secs
0 Sev Err Framing Secs, 0 Unavailable Secs
0 Line Errored Secs, 0 C-bit Errored Secs, 0 C-bit Sev Err Secs
0 Severely Errored Line Secs
0 Far-End Errored Secs, 0 Far-End Severely Errored Secs
0 CP-bit Far-end Unavailable Secs
0 Near-end path failures, 0 Far-end path failures
0 Far-end code violations, 0 FERF Defect Secs
0 AIS Defect Secs, 0 LOS Defect Secs
Transmitter is sending AIS.
Configuring Maintenance Data Link
MDL messages are used to communicate identification information between local and remote ports. The type
of information included in MDL messages includes the equipment identification code (EIC), location
identification code (LIC), frame identification code (FIC), unit, Path Facility Identification (PFI), port number,
and Generator Identification numbers.
To configure Maintenance Data Link (MDL), use the following commands:
PurposeCommand
Enters global configuration mode.Router# configure terminal
Selects the controller to configure and enters
controller configuration mode.
Router(config)# controller t3 slot/subslot/port
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
244 OL-14127-17
Configuring the 2-Port and 4-Port Channelized T3 SPAs
Optional Configurations
