Cisco ASR 1000 Series Software Configuration Guide

DETAILED STEPS
PurposeCommand or Action
(Optional) Enables configuration of up to 4094 dot1q VLANs per port
per Ethernet SPA, where:
Router(config)# hw-module subslot
slot/subslot ethernet vlan unlimited
Step 1
• slot—Specifies the chassis slot number where the SIP is installed.
• subslot—Specifies the slot of the SIP where the SPA is installed.
Specifies the Gigabit Ethernet interface to configure, where:Do one of the following:
Step 2
•
Router(config)# interface
gigabitethernet slot /subslot
/port.subinterface-number
• slot /subslot /port —Specifies the location of the interface. See the
Specifying the Interface Address on a SPA, on page 119.
• .subinterface-number—Specifies a secondary interface (subinterface)
number.
•
Router(config)# interface
tengigabitethernet slot /subslot
/port.subinterface-number
Defines the encapsulation format as IEEE 802.1Q (“dot1q”), where vlan-id
is the number of the VLAN (1–4094).
Router(config-subif)# encapsulation dot1q
vlan-id
Step 3
Sets a primary or secondary IP address for an interface, where:
Router(config-if)# ip address ip-address mask
[secondary]
Step 4
• ip-address —Specifies the IP address for the interface.
• mask —Specifies the mask for the associated IP subnet.
• secondary—(Optional) Specifies that the configured address is a
secondary IP address. If this keyword is omitted, the configured
address is the primary IP address.
VLAN Classification
When the hw-module subslot ethernet vlan unlimited command is configured, the default classification
of CoS bits 6-7 as high priority is still supported. However, other user-defined CoS values for high and
low priority classification using the plim qos input map cos queue command are not supported.
Note
Addition of Warning Message when Enabling VLAN Scale Configuration
Effective from Cisco IOS XE Release 2.1.0S, a warning message is displayed when enabling VLAN Scale
configuration.
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
130 OL-14127-17
Configuring the Ethernet SPAs
VLAN Classification
