Cisco ASR 1000 Series Software Configuration Guide

Configuration of the LAN/WAN-PHY controllers is described in the following tasks.
Configuring 1-Port 10-Gigabit Ethernet LAN/WAN PHY SPA
This section lists the basic mandatory configuration steps that should be performed to configure the 1-Port
10-Gigabit Ethernet LAN/WAN PHY SPA which is essential for the traffic to pass through the SPA. The
1-Port 10-Gigabit Ethernet LAN/WAN PHY SPA operates in either the LAN mode or the WAN mode. By
default, when the SPA is first inserted into the SIP, it operates in the WAN mode.
If the operation mode is changed from LAN to WAN or from WAN to LAN, an informational message
“%SPA(SPA-1X10GE-WL-V2): SPA reloaded to configure operation (LAN or WAN) mode” is displayed.
Depending on the mode to which it is changed, the respective operation mode (LAN or WAN) is displayed
in the message.
Note
Mandatory Initial Configuration Steps
To perform the initial configuration of the 1-Port 10-Gigabit Ethernet LAN/WAN PHY SPA and to allow the
traffic to pass through the SPA, complete these steps:
SUMMARY STEPS
1.
Router# configure terminal
2.
interface tengigabitethernet slot/subslot/port.subinterface-number
3.
ip address ip-address mask [secondary]
4.
mtu bytes
5.
standby ip ip-address secondary
6.
no shutdown
7.
exit
8.
exit
9.
show running-config interface Tengigabitethernet slot/subslot/port
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.Router# configure terminal
Step 1
Specific the 10-GB Ethernet interface to be configured, where:interface tengigabitethernet
slot/subslot/port.subinterface-number
Step 2
• slot/subslot/port—Indicates the location of the interface.
Example:
Router(config)# interface
tengigabitethernet 0/1/0
• subinterface-number—(Optional) Indicates a secondary subinterface
number.
Enters the interface configuration (config-if) mode after executing the
interface tengigabitethernet slot/subslot/port command.
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
148 OL-14127-17
Configuring the Ethernet SPAs
Configuring 1-Port 10-Gigabit Ethernet LAN/WAN PHY SPA
