Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Example:
Router(config-ctrlr-tug3)# tug-2 1 e1 1 cem-group
1 timeslots 1-31
Configuring SDH for AU-3 C-11
To enable an interface under SDH framing with AU-3 mapping after configuring the SONET controller,
perform the following steps:
SUMMARY STEPS
1.
Router(config)# controller sonet 0/1/0
2.
Router(config-controller)# framing sdh
3.
Router(config-controller)# aug mapping au-3
4.
Router(config-controller)# au-3 3
5.
Router(config-ctrlr-au3)# mode c-11
6.
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group 1 unframedor
DETAILED STEPS
PurposeCommand or Action
Selects the controller to be configured.
Router(config)# controller sonet 0/1/0
Step 1
Specifies the framing mode.Router(config-controller)# framing sdh
Step 2
Specifies AUG mapping.Router(config-controller)# aug mapping au-3
Step 3
Selects the AU-3 to be configured.
Router(config-controller)# au-3 3
Step 4
Specifies the channelization mode for the link.Router(config-ctrlr-au3)# mode c-11
Step 5
Creates a SAToP CEM group.
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group 1
unframedor
Step 6
or
Example:
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group
2015 timeslots 1-12
Creates a CESoPSN CEM group.
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
516 OL-14127-17
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring SDH for AU-3 C-11
