Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand
Specifies the interoperability mode used by a T3
controller.
• 0—Connects a T3/E3 controller to another
T3/E3 controller or to a Digital Link DSU
(DL3100 in T3 mode and DL3100E in E3
mode). This is the default.
• 1—Connects a T3/E3 controller to a Kentrox
DataSMART T3/E3 IDSU.
• 2—Connects a T3 controller to a Larscom
Access-T45 DS3 DSU.
• 3—Connects a T3 controller to an Adtran T3SU
300.
• 4—Connects a T3 controller to a Verilink HDM
2182.
T3
Router(config-if)# dsu mode {0 | 1 | 2 | 3 | 4}
E3
Router(config-if)# dsu mode {0 | 1}
Specifies the allowable bandwidth.
• kbps—The bandwidth range and increment
values are based on the specific DSU. Default
for T3 mode is 44010 kbps and 34010 kbps for
E3 mode.
◦
Digital Link DL3100 bandwidth range is
300 to 44210 kbps.
◦
Digital Link DL3100E bandwidth range
is 358 to 34010 kbps.
◦
Kentrox DataSMART T3/E3 IDSU
bandwidth range is 1000 to 34000 kbps
for E3 mode and 1500 to 44210 kbps for
T3 mode.
◦
Larscom Access-T45 DS3 bandwidth
range is 3100 to 44210 kbps.
◦
Adtran T3SU 300 bandwidth range is 80
to 44210 kbps.
◦
Verilink HDM 2182 bandwidth range is
1600 to 31600 kbps.
Router(config-if)# dsu bandwidth kbps
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
260 OL-14127-17
Configuring the 2-Port and 4-Port T3/E3 Serial SPA
Optional Configurations
