Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Creates an SAToP CEM group or a CESoPSN
CEM group.
Do one of the following:
Step 6
•
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group 1
unframed
•
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group 2015
timeslots list-of-timeslots
Configuring the Card Type and CEM Group for the 24-Port Channelized T1/E1 ATM CEoP SPA
To configure the card type and CEM group for the 24-Port Channelized T1/E1 ATM CEoP SPA, perform the
following steps:
SUMMARY STEPS
1.
Router(config)# card type {t1 | e1} slot subslot
2.
Router(config)# controller {t1 | e1} slot/subslot/port
3.
Router(config-controller)# cem-group group unframed
4.
Router(config-controller)# cem-group group timeslots list-of-timeslots
5.
Router(config-controller)# atm
6.
Router (config-controller)# exit
DETAILED STEPS
PurposeCommand or Action
Selects the card type as T1 or E1.
Router(config)# card type {t1 | e1} slot subslot
Step 1
Selects the controller for the SPA port to be configured as T1
or E1.
Router(config)# controller {t1 | e1}
slot/subslot/port
Step 2
Creates a SAToP CEM group and configures the port for the
clear-channel CEM mode.
Router(config-controller)# cem-group group
unframed
Step 3
Creates a CESoPSN CEM group and configures the port for
the channelized CEM mode.
Router(config-controller)# cem-group group
timeslots list-of-timeslots
Step 4
Configures the port to run in the clear-channel ATM mode and
creates an ATM interface to represent the port.
Router(config-controller)# atm
Step 5
or
Removes the ATM interface.
Exits the controller configuration mode.Router (config-controller)# exit
Step 6
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
478 OL-14127-17
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring Port Usage: An Overview
