Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Specifies AUG mapping.Router(config-controller)# aug mapping au-4
Step 3
Selects the AU-4 and TUG-3 to be configured.
Router(config-controller)# au-4 1 tug-3 2
Step 4
Specifies the channelization mode for TUG-3.Router(config-ctrlr-tug3)# mode c-12
Step 5
Creates an SAToP CEM group or a CESoPSN
CEM group.
Do one of the following:
Step 6
•
Router(config-ctrlr-tug3)# tug-2 1 e1 1 cem-group 1
unframed
•
Router(config-ctrlr-tug3)# tug-2 1 e1 1 cem-group 1
timeslots list-of-timeslots
Configuring SPA-1CHOC3-CE-ATM for SDH AU-3 C-11
To configure SPA-1CHOC3-CE-ATM for SDH AU-3 C-11, perform the following procedure:
SUMMARY STEPS
1.
Router(config)# controller sonet slot/subslot/interface-id
2.
Router(config-controller)# framing sdh
3.
Router(config-controller)# aug mapping au-3
4.
Router(config-controller)# au-3 3
5.
Router(config-ctrlr-au3)# mode c-11
6.
Do one of the following:
•
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group 1 unframed
•
Router(config-ctrlr-au3)# tug-2 1 t1 2 cem-group 2015 timeslots list-of-timeslots
DETAILED STEPS
PurposeCommand or Action
Selects the controller to be configured.
Router(config)# controller sonet slot/subslot/interface-id
Step 1
Specifies the framing mode.Router(config-controller)# framing sdh
Step 2
Specifies AUG mapping.Router(config-controller)# aug mapping au-3
Step 3
Selects the AU-3 to be configured.
Router(config-controller)# au-3 3
Step 4
Specifies the channelization mode for the link.Router(config-ctrlr-au3)# mode c-11
Step 5
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 477
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring Port Usage: An Overview
