Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Specifies the STS identifier.
Router(config-controller)# sts-1 2
Step 3
Specifies VT-15 as the STS-1 mode of operation.Router(config-ctrlr-sts1)# mode vt-15
Step 4
Creates a single Structure-Agnostic TDM over Packet
(SAToP) CEM group.
Do one of the following:
Step 5
•
Router(config-ctrlr-sts1)# vtg 2 t1 1 cem-group 1
unframed
or
Creates a Circuit Emulation Services over Packet
Switched Network (CESoPSN) CEM group.
•
•
•
Example:
Router(config-ctrlr-sts1)# vtg 2 t1 4 cem-group
2 timeslots list-of-timeslots
Configuring SPA-1CHOC3-CE-ATM for SDH AU-4 C-12
To configure SPA-1CHOC3-CE-ATM for SDH AU-4 C-12, perform the following procedure:
SUMMARY STEPS
1.
Router(config)# controller sonet slot/subslot/interface-id
2.
Router(config-controller)# framing sdh
3.
Router(config-controller)# aug mapping au-4
4.
Router(config-controller)# au-4 1 tug-3 2
5.
Router(config-ctrlr-tug3)# mode c-12
6.
Do one of the following:
•
Router(config-ctrlr-tug3)# tug-2 1 e1 1 cem-group 1 unframed
•
Router(config-ctrlr-tug3)# tug-2 1 e1 1 cem-group 1 timeslots list-of-timeslots
DETAILED STEPS
PurposeCommand or Action
Selects the controller to be configured.
Router(config)# controller sonet slot/subslot/interface-id
Step 1
Specifies SDH as the framing mode.Router(config-controller)# framing sdh
Step 2
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
476 OL-14127-17
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring Port Usage: An Overview
