Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Example:
Alarm reporting enabled for: SF SWLOF B1-TCA B2-TCA
PLOP WLOS
Example:
Example:
Rx(K1/K2): 00/00 Tx(K1/K2): 00/00
Example:
S1S0 = 00, C2 = 0x1A
Example:
PATH TRACE BUFFER: STABLE
Example:
Remote J1 Byte : passing_string_from_localend
Example:
Example:
BER thresholds: SD = 10e-6 SF = 10e-3
Example:
TCA thresholds: B1 = 10e-6 B2 = 10e-6 B3 = 10e-6
Configuring Alarm Reporting
The purpose of the WIS is to allow an Ethernet data streams that can be mapped directly to the STS-192c
stream or VC-4-64c streams at the physical level without requiring MAC or higher-layer processing. The
WIS adds path, line, and section overheads to generate the WIS frame. By default, line-level, section-level,
and path-level alarms, which can be configured and used to selectively report and manage the alarms internally,
are generated.
This section describes how to configure specific line-level, section-level, and path-level alarm reporting:
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 161
Configuring the Ethernet SPAs
Configuring Alarm Reporting
