Cisco ASR 1000 Series Software Configuration Guide

Release 3.3.0S, the SPA-1CHOC3-CE-ATM is supported only with these software images: ADVANCED ENTERPRISE SERVICES, ADVANCED ENTERPRISE
W/O CRYPTO, ADVANCED IP SERVICES, or ADVANCED IP SERVICES W/O CRYPTO. The SPA-1CHOC3-CE-ATM is not supported with these
software images: IP BASE and IP BASE W/O CRYPTO.
6
Restriction: Effective from Cisco IOS XE Release 3.4.0S, the SPA-2CHT3-CE-ATM is supported on all the Cisco ASR 1000 Series Routers except on the
Cisco ASR 1001 Router. However, the SPA-2CHT3-CE-ATM supports only the T3 ATM mode in Cisco IOS XE Release 3.4.0S and not the Circuit Emulation
(CEM) mode. Maximum Virtual Circuits supported are 1024. Interim Local Management Interface (ILMI) 1.0 is not supported. IETF RFC 2364 and 2516 for
Point-to-Point Protocol (PPP) over ATM is not supported. IETF RFC 1577 support for classical IP and Address Resolution Protocol (ARP) over ATM is not
supported. ATM Forum UNI 3.0, 3.1, and 4.0 is not supported. Effective from Cisco IOS XE Release 3.5.0S, the SPA-2CHT3-CE-ATM supports ATM on
clear-channel E3 SPA. All the existing ATM features are supported in the E3 mode. Effective from Cisco IOS XE Release 3.8.0S, the SPA-2CHT3-CE-ATM
is supported on the Cisco ASR 1001 Router. The SPA-2CHT3-CE-ATM on the Cisco ASR 1001 Router supports both the T3 and E3 ATM modes and does
not support the CEM mode.
7
Restriction: The SPA-24CHT1-CE-ATM is not supported on the Cisco ASR 1001 Router (1 RU chassis), but supported on all other ASR 1000 chassis. Effective
from Cisco IOS XE Release 3.4.0S, the SPA-24CHT1-CE-ATM supports only the CEM mode. Effective from Cisco IOS XE Release 3.4.0S, the
SPA-24CHT1-CE-ATM is supported only with these software images: ADVANCED ENTERPRISE SERVICES, ADVANCED ENTERPRISE W/O CRYPTO,
ADVANCED IP SERVICES, or ADVANCED IP SERVICES W/O CRYPTO. The SPA-24CHT1-CE-ATM is not supported with these software images: IP
BASE and IP BASE W/O CRYPTO.
Modular Optics Compatibility
Some SPAs implement small form-factor pluggable (SFP) optical transceivers to provide network connectivity.
An SFP module is a transceiver device that mounts into the front panel to provide network connectivity.
Cisco qualifies the SFP modules that can be used with SPAs.
The SPAs will only accept the SFP modules listed as supported in this document. An SFP module check
is run every time an SFP module is inserted into a SPA and only SFP modules that pass this check will
be usable.
Note
See the following for detailed information about the types of optics modules that have been qualified for use
with a SPA:
•
ATM SPA Optics Compatibility
•
CWDM Optics Compatibility for Built-in Gigabit Ethernet Ports (4x1GE) and All Gigabit Ethernet
SPAs Supported on the Cisco ASR 1000 Series Routers
•
DWDM Optics Compatibility for Built-in Gigabit Ethernet Ports (4x1GE) and Gigabit Ethernet SPAs
•
POS SPA SFP Optics Compatibility
•
Serial SPA SFP Optics Compatibility
•
CEoP SPA SFP Optics Compatibility
• Gigabit Ethernet SPA Optics Compatibility—See the SIP and SPA Product Overview chapter in Cisco
ASR 1000 Series Aggregation Services Routers SIP and SPA Hardware Installation Guide.
For more information about any of the supported transceivers for SPAs in these tables, refer to http://
www.cisco.com/en/US/products/hw/modules/ps5455/prod_installation_guides_list.html
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
20 OL-14127-17
SIP and SPA Product Overview
Modular Optics Compatibility
