PATH
AIS = 0 RDI = 1 FEBE = 21 BIP(B3) = 0
LOP = 1 NEWPTR = 0 PSE = 0 NSE = 0
Active Defects: None
Active Alarms: None
Alarm reporting enabled for: SF SLOS SLOF B1-TCA B2-TCA PLOP B3-TCA
ATM framing errors:
HCS (correctable): 0
HCS (uncorrectable): 0
APS
not configured
COAPS = 0 PSBF = 0
State: PSBF_state = False
Rx(K1/K2): 00/00 Tx(K1/K2): 00/00
Rx Synchronization Status S1 = 00
S1S0 = 00, C2 = 13
PATH TRACE BUFFER : STABLE
BER thresholds: SF = 10e-3 SD = 10e-6
TCA thresholds: B1 = 10e-6 B2 = 10e-6 B3 = 10e-6
Clock source: line
Configuring AToM VP Cell Mode Relay Support
To configure Any Transport over MPLS (AToM) Cell Mode Relay, perform the following procedure beginning
in global configuration mode:
SUMMARY STEPS
1.
Router(config)# interface atm slot/subslot/port.subinterface multipoint
2.
Router(config-if)# no ip address ip-address mask
3.
Router(config-if)# atm pvp vpi l2transport
4.
Router(config-if)# xconnect peer-ip-address vc-id {encapsulation mpls | pw-class pw-class-name }
5.
Router(config-if)# end
DETAILED STEPS
PurposeCommand or Action
Enters interface configuration mode for the indicated port on
the specified ATM SPA
Router(config)# interface atm
slot/subslot/port.subinterface multipoint
Step 1
Removes the IP address that is assigned to this interface (if one
has been configured).
Router(config-if)# no ip address ip-address mask
Step 2
Creates a permanent virtual path (PVP) used to multiplex (or
bundle) one or more virtual circuits (VCs).
Router(config-if)# atm pvp vpi l2transport
Step 3
Routes Layer 2 packets over a specified point-to-point VC by
using ATM over multiprotocol label switching (AToM).
Router(config-if)# xconnect peer-ip-address vc-id
{encapsulation mpls | pw-class pw-class-name }
Step 4
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
82 OL-14127-17
Configuring the ATM SPAs
Configuring AToM VP Cell Mode Relay Support
