Clock rates supported for EIA/TIA-232: 1.2K, 2.4K, 4.8K, 9.6K, 14.4K, 19.2K, 28.8K, 32K, 38.4K, 56K,
64K, 128K.
Note
Clock rates supported for EIA-530, EIA-530A, EIA-449, V.35(bps): 1.2K, 2.4K, 4.8K, 9.6K, 14.4K,
19.2K, 28.8K, 32K, 38.4K, 56K, 64K, 72K, 115.2K, 2.048M, 2.341M, 2.731M, 3.277M, 4.09M, 5.461M,
8.064K.
Note
Clock rates supported for X.21: 1.2K, 2.4K, 4.8K, 9.6K, 14.4K, 19.2K, 28.8K, 32K, 38.4K, 56K, 64K,
72K, 115.2K, 2.016M.
Note
Inverting the Clock Signal
Systems that use long cables or cables that are not transmitting the TxC (clock) signal might experience high
error rates when operating at higher transmission speeds. If a 4-Port Serial Interface SPA port is reporting a
high number of error packets, a phase shift might be the problem; inverting the clock might correct this phase
shift.
When the EIA/TIA-232 interface is a DTE, the invert-txclock command inverts the TxC signal the DTE
receives from the remote DCE. When the EIA/TIA-232 interface is a DCE, the invert-txclock command
inverts the clock signal to the remote DTE port. Use the no invert-txclock command to change the clock signal
back to its original phase.
Use the following commands when inverting the clock signal:
PurposeCommand
Enters global configuration mode.Router# configure terminal
Selects the interface to configure and enters interface
configuration mode.
Router(config)# interface serial slot/subslot/port
Inverts the transmit clock signal. When the
EIA/TIA-232 interface is a DTE, the invert txclock
command inverts the TxC signal the DTE receives
from the remote DCE. When the EIA/TIA-232
interface is a DCE, the invert txclock command
inverts the clock signal to the remote DTE port.
The no form of this command changes the clock
signal back to its original phase.
Router(config-if)# invert txclock
Invert the data signal.
The no form of this command disables the inversion
of the data stream.
Router(config-if)# invert data
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
284 OL-14127-17
Configuring the 4-Port Serial Interface SPA
Optional Configurations

Cisco ASR 1000 Series Specifications

General

Series	ASR 1000
Category	Network Router
Operating System	Cisco IOS XE
Memory	Up to 64 GB
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC options
Dimensions	Varies by model
Encryption	IPsec, SSL
Storage	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
