Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Enables AIS or RAI alarm forwarding on the selected E1 controller
interface for the 24-Port Channelized T1/E1 ATM CEoP SPA.
Do one of the following:
Step 4
•
Router(config-controller)# forward-alarm
ais/rai
or
Enables AIS or RAI alarm forwarding on the selected E1 controller
interface for the 2-Port Channelized T3/E3 ATM CEoP SPA.
•
•
Router(config-controller)# e1 1-21
forward-alarm ais/rai
Configuring the SONET Mode
To enable AIS/RAI forwarding on the CEoP SPAs for SONET mode, perform the following steps:
SUMMARY STEPS
1.
Router(config)# controller sonet slot/bay/port
2.
Router(config-controller)# sts-1 id
3.
Router(config-controller-sts)# vtg identifier t1 identifier forward-alarm {ais|rai}
DETAILED STEPS
PurposeCommand or Action
Enters the Controller configuration mode.Router(config)# controller sonet slot/bay/port
Step 1
Example:
orRouter(config)# controller sonet 0/1/0
or
Selects the controller to be configured.
Specifies the STS identifier.Router(config-controller)# sts-1 id
Example:
Step 2
Example:
Router(config-controller)# sts-1 1
Enables AIS or RAI alarm forwarding on the
selected interface for the SONET mode.
Router(config-controller-sts)# vtg identifier t1 identifier
forward-alarm {ais|rai}
Example:
Step 3
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
540 OL-14127-17
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring the SONET Mode
