Cisco ASR 1000 Series Software Configuration Guide

PurposeCommand or Action
Configures a PVC for the interface and assigns the PVC a VPI
or VCI. Do not specify 0 for the VPI or the VCI. See
pvc vpi | vci
Example:
Router(config-if)# pvc 10/11
Step 7
the"Configuring a Pseudowire for an ATM Connection, on
page 486" section for more details.
Configures a pseudowire to carry data from the clear-channel
ATM interface over the MPLS network. See the "Configuring
xconnect peer-router-id vcid {encapsulation mpls |
pseudowire-class name}
Step 8
a Pseudowire for an ATM Connection, on page 486" section
for more details.
Example:
Router(config-if)# xconnect 10.0.0.8 2
encapsulation mpls
Exits the interface configuration mode.end
Example:
Router(config-if)# end
Step 9
Examples for Configuring a 24-Port Channelized T1/E1 ATM CEoP SPA in the
Clear-Channel ATM Mode
The following example shows how to verify the configuration of the 24-Port channelized T1/E1 CEoP SPA:
Router# show controllers T1 1/1/14
T1 1/1/14 is up.
Applique type is SPA-24CHT1-CE-ATM
Cablelength is short 133
No alarms detected.
alarm-trigger is not set
Soaking time: 3, Clearance time: 10
AIS State:Clear LOS State:Clear LOF State:Clear
Framing is ESF, Line Code is B8ZS, Clock Source is Line.
Data in current interval (87 seconds elapsed):
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 0 Unavail Secs
0 Near-end path failures, 0 Far-end path failures, 0 SEF/AIS Secs
Data in Interval 1:
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 0 Unavail Secs
0 Near-end path failures, 0 Far-end path failures, 0 SEF/AIS Secs
Data in Interval 2:
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 0 Unavail Secs
0 Near-end path failures, 0 Far-end path failures, 0 SEF/AIS Secs
Data in Interval 3:
0 Line Code Violations, 3 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
1 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 1 Unavail Secs
0 Near-end path failures, 0 Far-end path failures, 0 SEF/AIS Secs
Total Data (last 3 15 minute intervals):
0 Line Code Violations, 3 Path Code Violations,
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 511
Configuring the Circuit Emulation over Packet Shared Port Adapter
Examples for Configuring a 24-Port Channelized T1/E1 ATM CEoP SPA in the Clear-Channel ATM Mode
