Cisco ASR 1000 Series Software Configuration Guide

SUMMARY STEPS
1.
enable
2.
configure terminal
3.
controller{ t1 | e1 } slot/subslot/port
4.
atm
5.
exit
6.
interface atm slot/subslot/port.subinterface number point-to-point
7.
pvc vpi | vci
8.
xconnect peer-router-id vcid {encapsulation mpls | pseudowire-class name}
9.
end
DETAILED STEPS
PurposeCommand or Action
Enables the privileged EXEC mode.enable
Step 1
Example:
Router> enable
Enter your password, if prompted.
Enters the global configuration mode.configure terminal
Example:
Router# configure terminal
Step 2
Selects the T1 or E1 controller for the slot, the subslot, or the
port on the SPA.
controller{ t1 | e1 } slot/subslot/port
Example:
Router(config)# controller t1 0/0/2
Step 3
Configures the port or the slot for the clear-channel ATM.atm
Example:
Router(config-controller)# atm
Step 4
Returns to the global configuration mode.exit
Example:
Router(config-controller)# exit
Step 5
Specifies the ATM interface for the SPA port mentioned in
Step 1.
interface atm slot/subslot/port.subinterface
number point-to-point
Example:
Router(config)# interface atm 0/1/2.10
point-to-point
Step 6
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS
XE Everest 16.5
510 OL-14127-17
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring a 24-Port Channelized T1/E1 ATM CEoP SPA in the Clear-Channel ATM Mode
