Cisco ASR 1000 Series Software Configuration Guide

SUMMARY STEPS
1.
Router# enable
2.
Router# configure terminal
3.
Router(config)# interface atm slot/subslot/port.subinterface point-to-point
4.
Router(config-subif)# pvc vpi /vci l2transport
5.
Router(cfg-if-atm-l2trans-pvc)# encapsulation {aalo | aal5}
6.
Router(cfg-if-atm-l2trans-pvc)# xconnect peer-router-id vcid {encapsulation mpls | pseudowire-class
name }
7.
Router(config-if-atm-l2trans-pvc-xconn)# backup peer peer-router-id peer-vcid {priority peer-priority
| pw-class name }
8.
Router(config-if-atm-l2trans-pvc-xconn)# backup delay enable-delay {disable delay | never}
DETAILED STEPS
PurposeCommand or Action
Enables the privilege exec mode.Router# enable
Step 1
Enters the global configuration mode.Router# configure terminal
Step 2
Enters the subinterface configuration mode pertaining to the specified slot
and port number to establish a P2P connection in which the
SPA-2CHT3-CE-ATM is installed.
Router(config)# interface atm
slot/subslot/port.subinterface point-to-point
Step 3
Creates a permanent virtual circuit for the ATM interface and assigns the
PVC a VPI ID and VCI ID:
Router(config-subif)# pvc vpi /vci
l2transport
Step 4
•
vpi specifies the virtual path identifier (0 to 255).
•
vci specifies the virtual channel identifier. Valid values are 32 to 1
less than the value specified using the atm vc-per-vp command.
Do not specify 0 for both the VPI and
VCI.
Note
Specifies the ATM adaptation layer (AAL) for the PVC:Router(cfg-if-atm-l2trans-pvc)#
encapsulation {aalo | aal5}
Step 5
• aal0—Cell mode
• aal5—Packet mode
Configures a pseudowire to transport data from the ATM interface across
the MPLS network.
Router(cfg-if-atm-l2trans-pvc)# xconnect
peer-router-id vcid {encapsulation mpls |
pseudowire-class name }
Step 6
•
peer-router-id is the IP address of the remote PE peer router.
•
vcid is a 32-bit identifier that is to be assigned to the pseudowire. The
same vcid must be used for both ends of the pseudowire.
•
encapsulation mpls sets MPLS for the tunneling mode.
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide, Cisco IOS XE
Everest 16.5
OL-14127-17 491
Configuring the Circuit Emulation over Packet Shared Port Adapter
Configuring Pseudowire Redundancy
