DEQX User Manual
160
ANALOG AUDIO INPUTS
*4 Jumper-selectable to reduce sensitivity (see Appendix D). The given value is the factory
default.
ANALOG AUDIO OUTPUTS
*5 Not applicable to HDP-Express II.
*6 Jumper-selectable in five ranges up to 22.3 dBu balanced, 15.7 dBu unbalanced (see
Appendix D). The given value is the factory default.
*7 Into an earth-referenced amplifier i.e. one where the RCA ground pin connects to mains
ground. This is normally the case. The precise output impedance is 75 ohms, plus 75 ohms in
parallel with whatever the amplifier puts in series between its RCA connector and mains
ground. If the latter is open, then the impedance can be as high as 150 ohms (such as may
happen with a two-pin power connector).
CALIBRATION KIT
HARDWARE AND GENERAL
Balanced
Unbalanced
Full scale input level
17 dBu / 5.5 VRMS
9.3 dBu / 2.25 VRMS (*4)
Input impedance
50 kΩ
50 kΩ
A/D convertor
24-bit, 96 kHz
Signal-to-noise ratio
107 dB, A-weighted
Balanced (*5)
Unbalanced
Full scale output level (*6)
17.4 dBu / 5.7 VRMS
10.8 dBu / 2.7 VRMS
Output impedance
150 Ω
75 Ω (*7)
Frequency response
10 Hz – 45 kHz
Total harmonic distortion
0 0008% (analog in to analog out)
Signal-to-noise ratio
107 dB, A-weighted
Standard Calibration Kit
Reference Calibration Kit
Calibration file
20 Hz – 20 kHz
20 Hz – 35 kHz
Maximum SPL
127 dB
140 dB
Phantom power
48 V
48 V
Computer control
USB 2.0
Mains input voltage
HDP-5, PreMATE, PreMATE+, HDP-Express II: 100 – 240
V AC, 50 – 60 Hz, auto-select
HDP-4: 100 – 120 or 220 – 240 V AC, 50 – 60 Hz, switch-
selectable on rear panel
Fuse rating
100 – 120V: 2 Amps; 220 – 240V: 1 Amp
Power consumption
30 W (max)
