DEQX User Manual
7.1 CREATE A CALIBRATION TEMPLATE
The calibration wizard can be entered directly from the last
screen of the speaker measurement wizard (page 52). Or,
start the calibration wizard by clicking on the Calibrate
Speakers button in the Wizard toolbar or by selecting it from the Tools menu. If
entering directly from the speaker measurement wizard, Screens 2 and 3 below will not
be displayed.
The calibration wizard will take you through a series of screens. Select the necessary
options on each screen and click the Next button. If you realize you've made a mistake
or need to check what you've done, click the Back button.
Screen 1. If you have more than one project open (page 149), this screen is used to
select the project in which the calibration will be done. Otherwise, this is just an
informational screen.
Screen 2. Create a new calibration template, or
select an existing calibration template to open.
(The following steps assume that you have
selected “Create a new speaker calibration.”)
Screen 3. Select the “Single amp” speaker configuration mode. (See Chapter 8 for the
“Subwoofer” option and Chapter 13 for the “Bi amp” and “Tri amp” options.)
Screen 4. Select or confirm the measurement that will be used to create the correction
set. (If you measured both speakers, select both of those measurements here.) Only
measurements that match the chosen configuration can be selected. (You cannot, for
example, calibrate a speaker with a subwoofer measurement.)
Screen 4a. If you have selected only one measurement, you will be given a warning.
Click Next to proceed.
