SPECIFICATIONS
Specifications are subject to change without notice.
AUDIO PROCESSING
*1 Available slopes are subject to filter delay limits.
*2 Ten bands available if Preference EQ is not needed.
DIGITAL AUDIO INPUTS
DIGITAL AUDIO OUTPUTS (*3)
*3 All digital outputs are S/PDIF via BNC 75Ω connector.
48 to 300 dB/octave (linear-phase)
6 to 96 dB/octave (Linkwitz-Riley and Butterworth)
6 to 300 dB/octave, 20 Hz to 20 kHz
From 2.5 ms, typically 15 ms depending on filters
Better than 0.5 ms, typical
Better than 0.2 dB, typical
Seven bands, 1 Hz to 48 kHz, −300 to +40 dB, Q 0.01 to 17
Three bands, 20 Hz to 20 kHz, gain to +/− 9 dB, Q 0.5 to 10
24-bit, 44.1 to 192 kHz, 75Ω
24-bit, 44.1 to 192 kHz, 110Ω
Asynchronous USB Audio Class 2, 24-bit, 44.1 to 192 kHz.
Driver not required for Mac OS X; XS-1 driver supplied for
Microsoft Windows.
