E 10
- Connect the hydraulic hoses (11) and
the supply line of the spraying system
(12) and chain lubrication system (13)
of the slewing belt with the corre-
sponding quick-release couplings of
the feeder.
- Remove the dummy connector (14)
and insert the slewing belt connector;
secure it with the corresponding
shackles.
m
All hydraulic hoses (11) must be coupled
properly to prevent a greater increase in
pressure. Check that connected cou-
plings fit properly!
