Chapter 11
| Link Aggregation Commands
Trunk Status Display Commands
– 400 –
Console#show lacp 1 internal
Port Channel : 1
Admin Key : 0
Oper Key : 4
Timeout : Long
------------------------------------------------------------
Member Port : Eth 1/1
Periodic Time : 30 seconds
System Priority : 32768
Port Priority : 32768
Admin Key : 4
Oper Key : 4
Admin State : Defaulted, Aggregatable, Long Timeout, Actvie LACP
Oper State : Distributing, Collecting, Synchronization, Aggregatable,
Long Timeout, Actvie LACP
.
.
.
Marker Received Number of valid Marker PDUs received by this channel group.
MarkerResponsePD
U Sent
Number of valid Marker Response PDUs transmitted from this channel group.
MarkerResponsePD
U Received
Number of valid Marker Response PDUs received at this channel group.
LACPDUs Unknown
Pkts
Number of frames received that either (1) Carry the Slow Protocols Ethernet
Type value, but contain an unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the Slow Protocols Ethernet
Type.
LACPDUs Illegal
Pkts
Number of frames that carry the Slow Protocols Ethernet Type value, but
contain a badly formed PDU or an illegal value of Protocol Subtype.
Table 74: show lacp internal - display description
Field Description
Port Channel Local identifier for a link aggregation group.
Admin Key Current administrative value of the key for the aggregation port.
Oper Key Current operational value of the key for the aggregation port.
Timeout The timeout to wait for the next LACP data unit (LACPDU)
Member Port The ports active in this link aggregation group.
Periodic Time Number of seconds before invalidating received LACPDU information.
System Priority LACP system priority assigned to this port channel.
Port Priority LACP port priority assigned to this interface within the channel group.
LACPDUs Internal Number of seconds before invalidating received LACPDU information.
Table 73: show lacp counters - display description (Continued)
Field Description
