Chapter 11
| Link Aggregation Commands
Trunk Status Display Commands
– 401 –
Console#show lacp 1 neighbors
Port Channel : 1
------------------------------------------------------------
Member Port : Eth 1/1
Partner Admin System ID : 32768, 00-00-00-00-00-00
Partner Oper System ID : 32768, 70-72-CF-9D-73-54
Partner Admin Port ID : 32768, 1
Partner Oper Port ID : 128, 1
Partner Admin Key : 0
Partner Oper Key : 82
Partner Admin State : Defaulted, Distributing, Collecting,
Synchronization, Long Timeout, Passive LACP
Partner Oper State : Distributing, Collecting, Synchronization,
Aggregatable, Long Timeout, Actvie LACP
Partner Admin System ID : 32768, 00-00-00-00-00-00
Partner Oper System ID : 32768, 00-12-CF-61-24-2F
Partner Admin Port Number : 1
Partner Oper Port Number : 1
Port Admin Priority : 32768
Port Oper Priority : 32768
Admin Key : 0
Oper Key : 3
Admin State: defaulted, distributing, collecting,
synchronization, long timeout,
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
â—†
Expired – The actor’s receive machine is in the expired state;
â—†
Defaulted – The actor’s receive machine is using defaulted operational
partner information, administratively configured for the partner.
â—†
Distributing – If false, distribution of outgoing frames on this link is disabled;
i.e., distribution is currently disabled and is not expected to be enabled in
the absence of administrative changes or changes in received protocol
information.
â—†
Collecting – Collection of incoming frames on this link is enabled; i.e.,
collection is currently enabled and is not expected to be disabled in the
absence of administrative changes or changes in received protocol
information.
â—†
Synchronization – The System considers this link to be IN_SYNC; i.e., it has
been allocated to the correct Link Aggregation Group, the group has been
associated with a compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and operational Key
information transmitted.
â—†
Aggregation – The system considers this link to be aggregatable; i.e., a
potential candidate for aggregation.
â—†
Long timeout – Periodic transmission of LACPDUs uses a slow transmission
rate.
â—†
LACP-Activity – Activity control value with regard to this link.
(0:Passive;1:Active)
Table 74: show lacp internal - display description (Continued)
Field Description
