Chapter 11
| Link Aggregation Commands
Trunk Status Display Commands
– 402 –
Console#show lacp sysid
Port Channel System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-30-F1-8F-2C-A7
2 32768 00-30-F1-8F-2C-A7
3 32768 00-30-F1-8F-2C-A7
4 32768 00-30-F1-8F-2C-A7
5 32768 00-30-F1-8F-2C-A7
6 32768 00-30-F1-8F-2C-A7
7 32768 00-30-F1-D4-73-A0
8 32768 00-30-F1-D4-73-A0
9 32768 00-30-F1-D4-73-A0
10 32768 00-30-F1-D4-73-A0
11 32768 00-30-F1-D4-73-A0
12 32768 00-30-F1-D4-73-A0
.
.
.
Table 75: show lacp neighbors - display description
Field Description
Port Channel Local identifier for a link aggregation group.
Member Port The ports active in this link aggregation group.
Partner Admin
System ID
LAG partner’s system ID assigned by the user.
Partner Oper
System ID
LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port ID
Current administrative value of the port priority and the port number for the
protocol partner.
Partner Oper
Port ID
Operational port priority and the port number assigned to this aggregation
port by the port’s protocol partner.
Partner Admin Key Current administrative value of the Key for the protocol partner.
Partner Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding table.)
Partner Oper State Operational values of the partner’s state parameters. (See preceding table.)
Table 76: show lacp sysid - display description
Field Description
Channel group A link aggregation group configured on this switch.
System Priority
*
* The LACP system priority and system MAC address are concatenated to form the LAG system ID.
LACP system priority for this channel group.
System MAC
Address*
System MAC address.
