TAP Series Switch Command Line Reference
54
Flow label value and wildcard bits both have
20bits, if a bit in wildcard is 0 means this bit
needs to check, otherwise this bit should be
ignored.
Parameter
“
any
”
indicates ipv6 packets with
any flow label value can match this rule.
dscp DSCP_VALUE
Specify the DSCP in IPv4 packets value of the
inner-match rule.
DSCP = Differentiated Services Code Point.
Valid range of DSCP value is 0 – 63.
ip-precedence PRECEDENCE_VALUE
Specify the IP precedence in IPv4 packets of
the inner-match rule.
Valid range of IP precedence value is 0
–
7.
DSCP & ip precedence configurations are
exclusive
first-fragment
Match packets with first fragment
non-first-fragment
Match packets with non first fragment
non-fragment
Match packets with non fragment
non-or-first-fragment
Match packets with non first fragment
small-fragment
Match packets with small fragment
any-fragment
Match packets with any fragment
options
Match packets with IP options
vlan ( VLAN_ID VLAN_WILD | any )
Specify the outer vlan id of the inner-match
rule.
The valid range for vlan id is 0-4095.
The valid range for vlan id wildcard bits is 0x0-
0xFFF.
Vlan id and wildcard bits both have 12bits, if a
bit in wildcard is 0 means this bit needs to
check, otherwise this bit should be ignored.
Parameter “any” indicates packets with any
outer vlan id can match this rule.
inner-vlan ( VLAN_ID VLAN_WILD | any )
Specify the inner vlan id of the inner-match
rule.
The valid range for vlan id is 0-4095.
The valid range for vlan id wildcard bits is 0x0-
0xFFF.
Vlan id and wildcard bits both have 12bits, if a
bit in wildcard is 0 means this bit needs to
check, otherwise this bit should be ignored.
Parameter
“
any
”
indicates packets with any
inner vlan id can match this rule.
cos COS_ID
Specify the outer CoS value of the inner-match
rule.
