FS TAP Series User Manual

TAP Series Switch Command Line Reference
55
CoS = Class of Service.
The valid range of Cos is 0 to 7.
inner-cos COS_ID
Specify the inner CoS value of the inner-match
rule.
CoS = Class of Service.
The valid range of Cos is 0 to 7.
ether-type ( ETHER_TYPE_VALUE
ETHER_TYPE_WILD_VALUE | any )
Specify the ether-type of the inner-match rule.
The valid range for ether-type is 0x600-
0xFFFF.
The valid range for wildcard bits is 0x600-
0xFFFF.
Ether-type value and wildcard bits both have
16bits, if a bit in wildcard is 0 means this bit
needs to check, otherwise this bit should be
ignored.
Parameter
“
any
”
indicates packets with any
ethertype value can match this rule.
src-mac ( MATCH_MAC_ADDR
MATCH_MAC_ADDR_WILD | any | host
MATCH_MAC_ADDR )
Specify the source mac address in
HHHH.HHHH.HHHH format.
Use a mac address and wildcard bits to specify
a batch of mac addresses. If a bit in wildcard is
0 means this bit needs to check, otherwise
this bit should be ignored.
Use the parameter
“
host
”
and a mac address
to specify an exactly mac address.
Use the parameter “any” to indicate packets
with any source mac address value can match
this rule.
dest-mac ( MATCH_MAC_ADDR
MATCH_MAC_ADDR_WILD | any| host
MATCH_MAC_ADDR )
Specify the destination mac address in
HHHH.HHHH.HHHH format.
Use a mac address and wildcard bits to specify
a batch of mac addresses. If a bit in wildcard is
0 means this bit needs to check, otherwise
this bit should be ignored.
Use the parameter
“
host
”
and a mac address
to specify an exactly mac address.
Use the parameter “any” to indicate packets
with any destination mac address value can
match this rule.
Command Mode
Inner-match Configuration
