Fujitsu PRIMERGY RX1330 M3

RX1330 M3 Upgrade and Maintenance Manual 109
Power supply unit (PSU)
6.3 Redundant power supply
Figure 26: PSU bays
6.3.1 Installing a hot-plug PSU
6.3.1.1 Preliminary steps
No steps needed.
6.3.1.2 Removing the dummy cover
Figure 27: Removing a dummy cover
Ê Press in on both release latches (1) and remove the dummy cover (2).
V CAUTION!
Keep the dummy cover for future use. If a PSU is removed and not
immediately replaced by a new one, a dummy cover must be reinstalled
in the bay to comply with applicable EMC regulations and satisfy cooling
requirements.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
PSU 1 PSU 2
