RX1330 M3 Upgrade and Maintenance Manual 301
System board and components
14.6.3 Replacing the iRMC microSD card
14.6.3.1 Preliminary steps
Ê "Locating the defective server" on page 50
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
Ê Remove the riser module 1 as described in section "Removing a riser
module" on page 66.
14.6.3.2 Replacing the iRMC microSD card
Ê Remove the defective iRMC microSD card as described in section
"Removing the iRMC microSD card" on page 300.
Ê Install the new iRMC microSD card as described in section "Installing the
iRMC microSD card" on page 298.
14.6.3.3 Concluding steps
Ê Install the riser module 1 as described in section "Installing a riser module"
on page 68.
Ê "Reassembling" on page 60
Ê "Connecting the power cord" on page 64
Ê "Switching on the server" on page 66
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: a pair of side-cutting pliers
