16.3 Onboard settings
Figure 247: Jumper
Print Setting
PWD-CLR open: normal operation (default)
short: clear password and apply the default BIOS settings
RCVR 1-2 normal operation (default)
2-3 recovery mode
Password
Clear
enabled
Setting
Recovery
BIOS
enabled
PWD-CLR
Jumper
Description
RCVR
Default
Password Clear
and Recovery
BIOS disabled
