RX1330 M3 Upgrade and Maintenance Manual 267
13.3.3 Replacing the front VGA board
13.3.3.1 Preliminary steps
Ê "Locating the defective server" on page 50
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
Ê "Removing the front panel module" on page 259
13.3.3.2 Removing the defective front VGA board
Ê Remove the front VGA board as described in section "Removing the front
VGA board" on page 266.
13.3.3.3 Installing the new front VGA board
Ê Install the front VGA board as described in section "Installing the front VGA
board" on page 264.
13.3.3.4 Concluding steps
Ê "Installing the front panel module" on page 261
Ê "Reassembling" on page 60
Ê "Connecting the power cord" on page 64
Ê "Switching on the server" on page 66
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
