312 Upgrade and Maintenance Manual RX1330 M3
15.2 Cabling plans
Overview cabling plans
Basic cabling
– "Basic cabling: 4x 3.5-inch HDD" on page 313
– "Basic cabling: 8x 2.5-inch HDD" on page 313
– "Basic cabling: 10x 2.5-inch HDD" on page 314
Power cabling
– "Power cabling: 4x 3.5-inch HDD, standard PSU" on page 314
– "Power cabling: 8x 2.5-inch HDD, redundant PSU" on page 315
– "Power cabling: 10x 2.5-inch HDD, redundant PSU" on page 315
Cabling 3.5-inch HDD configurations
– "Drive/HDD cabling: 4x 3.5-inch HDD onboard controller" on page 316
– "Drive/HDD cabling: 4x 3.5-inch HDD PRAID controller" on page 316
Cabling 2.5-inch HDD configurations
– "Drive/HDD cabling: 4x 2.5-inch HDD onboard controller" on page 317
– "Drive/HDD cabling: 4x 2.5-inch HDD PRAID controller" on page 317
– "Drive/HDD cabling: 8x 2.5-inch HDD PRAID controller" on page 318
– "Drive/HDD cabling: 10x 2.5-inch HDD PRAID controller" on page 318
C18 T26139-Y4040-V20 CBL_SAS3.0_385 RAID controller to 4x 2.5-inch
HDD backplane, rectangle,
Expander
C19 T26139-Y4031-V103 CBL FBU03 700 RAID controller to FBU
C20 T26139-Y4031-V108 CBL_TFM_EP540_750 EP540i / EP580i to FBU
C21 T26139-Y2361-V103 CBL_HDD_SIGNAL_220 EP540i / EP580i to System
board
C22 T26139-Y4040-V71 CBL_4HDD_DATA3.5 L EP540i / EP580i to 4x 3.5-
inch HDD backplane
No. Part number Description From - to
