RX1330 M3 Upgrade and Maintenance Manual 197
Expansion cards and backup units
9.4 Expansion cards and riser cards
9.4.1 Installing an expansion card
9.4.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
Ê Remove the corresponding riser module as described in section "Removing
a riser module" on page 66.
9.4.1.2 Removing the slot cover
Figure 114: Removing the slot cover - example riser module 1
Ê Remove the slot cover.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: tool-less
