232 Upgrade and Maintenance Manual RX1330 M3
11.1 Basic information
Supported CPUs
– one Intel
®
Quad-Core Xeon E3-12xxv6 or one Dual Core i3-7xxx or one
Dual Core Pentium G4xxx CPU
– one CPU socket LGA 1151
I For system relevant information, refer to your server’s hardware
configurator available online at the following address:
http://ts.fujitsu.com/products/standard_servers/index.htm
For Japan:
http://jp.fujitsu.com/platform/server/primergy/system/
11.2 Upgrading or replacing the CPU
V CAUTION!
CPUs are modules which are extremely sensitive to electrostatic
discharges and therefore must always be handled with care. After a CPU
has been removed from its protective sleeve or from its socket, place it
with its smooth side down on a non-conducting, antistatic surface. Never
push a CPU over a surface.
11.2.1 Preliminary steps
Ê "Locating the defective server" on page 50
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
