Fujitsu PRIMERGY RX1330 M3

RX1330 M3 Upgrade and Maintenance Manual 115
Power supply unit (PSU)
6.3.2.3 Installing the dummy cover
Figure 35: Installing the dummy cover
Ê Insert the dummy cover into the empty bay with the impressed arrow symbol
facing to the top (see circle).
Ensure that the upper rear cant of the dummy cover fits under the PSU cage.
Ê Push the dummy cover into its bay until it locks in place.
V CAUTION!
Always install dummy covers into unused bays to comply with
applicable EMC regulations and satisfy cooling requirements.
6.3.3 Replacing a hot-plug PSU
V CAUTION!
● When replacing a PSU in a non-redundant PSU configuration, the
server must be switched off first.
● Replace the PSU after specifying the one that breaks down at work
by revitalization.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
