286 Upgrade and Maintenance Manual RX1330 M3
System board and components
14.4.1.2 Installing the TPM
Figure 198: TPM installation kit
Figure 199: Position on the system board
Figure 200: Inserting the TPM spacer on the system board
Ê Insert the TPM spacer into the hole on the system board.
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2
Front
VGA
I2C5
iRMC
S4
Riser card (x4)
Indicate
CSS
TPM
Riser card (x8)
Shared
LAN
Standard
LAN
Slot2
Slot1
Jumper
Micro
SD
SATA1-4
DIMM2A
DIMM1A
DIMM2B
DIMM1B
Managem.
LAN
Intel
i210
Service
LAN
Intel
i210
PWR4
SATA5
DOM
SATA6
DOM
