290 Upgrade and Maintenance Manual RX1330 M3
System board and components
I For detailed information on how to access the BIOS and modify
settings, refer to the corresponding BIOS Setup Utility reference
manual.
Ê "Suspending BitLocker functionality" on page 71
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
14.4.2.2 Removing the TPM
Ê "Removing the defective system board" on page 305
Ê Lay the system board on a soft, antistatic surface with its component side
facing down.
Figure 203: Removing the TPM screw
Ê Locate the slotted lower end of the TPM screw (1).
Ê Carefully loosen the TPM screw using a thin slotted screw driver (e.g.
watchmaker's screw driver) or the dedicated TPM screw driver (for
Japan) (2).
