294 Upgrade and Maintenance Manual RX1330 M3
System board and components
14.5 SATA DOM
14.5.1 Installing the SATA DOM
I In the RX1330 M3 two SATA DOM can be installed. In the case of
installing the second SATA DOM, no ODD can be used.
14.5.1.1 Preliminary steps
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
14.5.1.2 Installing the SATA DOM
Figure 205: SATA DOM
Figure 206: Positions SATA DOM
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Front
VGA
I2C5
iRMC
S4
Indicate
CSS
TPM
Riser card (x8)
Shared
LAN
Standard
LAN
Slot1
Jumper
Micro
SD
SATA1-4
DIMM2B
DIMM1B
Managem.
LAN
Intel
i210
Service
LAN
Intel
i210
PWR4
SATA5
DOM
SATA6
DOM
