32 Upgrade and Maintenance Manual RX1330 M3
2.4 Documents you need at hand
Maintenance procedures may include references to additional documentation.
When preparing the maintenance task, ensure that all required manuals are
available according to the overview below.
I – Ensure to store all printed manuals enclosed with your server in a
save place for future reference.
– Unless stated otherwise, all manuals are available online at
http://manuals.ts.fujitsu.com under x86 Servers.
For Japan please use the following address:
http://www.fujitsu.com/jp/products/computing/servers/primergy/manual/
Phillips
PH1 / (+) No. 1
0.4 Nm
TFM
M2.5 x 4 mm
(silver)
A3C40137316
Hexagon bolt
0.6 Nm
Front VGA
connector
UNC #4-40x7.8 mm
(silver)
V226827-B265-V5
Phillips
PH1 / (+) No. 1
0.4 Nm
Front panel on
QRL
M2.5 x 8 mm
(silver)
C26192-Y10-C174
Screw driver/
bit insert
Torque
Screw Usage Type
Table 3: List of used screws (Japan)
