Fujitsu PRIMERGY RX1330 M3

RX1330 M3 Upgrade and Maintenance Manual 31
Before you start
List of used screws for Japan
Screw driver/
bit insert
Torque
Screw Usage Type
Phillips
PH2 / (+) No. 2
0.6 Nm
Slot bracket to
chassis,
system board
M3 x 6 mm
(silver)
F6-SW2N3-06121
Phillips
PH2 / (+) No. 2
0.6 Nm
Slot bracket to
expansion
card
M3 x 5 mm
(silver)
F6-SW2N3-06121
Phillips
PH2 / (+) No. 2
0.6 Nm
3.5-inch HDD UNC 6-32 x 3.5 mm
(silver)
A3C40151505
Phillips
PH1 / (+) No. 1
0.4 Nm
Front VGA,
2.5-inch HDD
M3 x 3.5 mm
(silver)
CA32432-0023
Special bit insert
0.6 Nm
TPM screw
REM 3 x 15 mm
(black)
C26192-Y10-C176
Phillips
PH1 / (+) No. 1
0.09 Nm
ODD latch
M2 x 3mm
(black)
F6-SW4N2-03121
Phillips
PH1 / (+) No. 1
0.06 Nm
UFM nylon
screw
M3 x 4 mm
(white)
A3C40109082
Table 3: List of used screws (Japan)
