Fujitsu PRIMERGY RX1330 M3

142 Upgrade and Maintenance Manual RX1330 M3
Hard disk drive (HDD) / solid state drive (SSD)
7.2.3 Configuration with up to eight HDD/SSD modules
Figure 60: Configuration with up to eight HDDs/SSDs
The HDD/SSD numbering as listed in the ServerView RAID Manager:
Position Logical drive number ServerView RAID Manager display name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
[4] 4 Vendor Product (4)
[5] 5 Vendor Product (5)
[6] 6 Vendor Product (6)
[7] 7 Vendor Product (7)
