RX1330 M3 Upgrade and Maintenance Manual 151
Hard disk drive (HDD) / solid state drive (SSD)
7.2.8 Replacing the 4 x 2.5-inch HDD backplane
7.2.8.1 Preliminary steps
Ê "Locating the defective server" on page 50
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
Ê Release all HDD/SSD modules and pull them out a few centimeters, see
section "Removing 2.5-inch HDD/SSD modules" on page 147
I The HDD/SSD modules need not to be removed. But if you want to
remove them nevertheless, check if all HDD/SSD modules are
uniquely identified so that you can reinsert them into their original
bays.
7.2.8.2 Removing the defective 4 x 2.5-inch HDD backplane
I For configurations with up to four 2.5-inch HDDs/SSDs, please refer to:
section "Right side 4 x 2.5-inch HDD backplane (A3C40196777)" on
page 153.
For configurations with up to eight 2.5-inch HDDs/SSDs, please refer to:
section "Left side 4 x 2.5-inch HDD backplane (A3C40196780)" on
page 152 or "Right side 4 x 2.5-inch HDD backplane (A3C40196777)" on
page 153.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
