Front panel
13.2.1.2 Removing the front panel module
Figure 170: Disconnecting the cables (A)
Ê Disconnect the front panel cable (1) and the front USB cable (2) from the
system board.
Figure 171: Disconnecting the cables (B)
Ê If applicable, disconnect the front VGA cable (black cable) from the system
board.
