164 Upgrade and Maintenance Manual RX1330 M3
Hard disk drive (HDD) / solid state drive (SSD)
7.2.11 Upgrading configuration from up to four to up to
eight 2.5-inch HDDs/SSDs
V CAUTION!
All data on all HDDs/SSDs in the array will be lost when deleting the
RAID array! Be sure to back up your data before deleting a RAID array.
For further information, please refer to the "ServerView Suite RAID
Management" user guide.
7.2.11.1 Preliminary steps
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
7.2.11.2 Removing the ODD lock
Ê If an ODD has been installed, remove the ODD as described in section
"Removing the ODD" on page 252.
Figure 83: Removing the ODD lock (A)
Ê Push the ODD lock in direction of the arrow.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
