326 Upgrade and Maintenance Manual RX1330 M3
16.2.1.2 Onboard indicators and controls
Figure 237: Onboard indicators and Indicate CSS button
I LEDs A, B and C are visible from outside on the server rear. All other
LEDs are only visible if the server cover has been opened.
If the server has been powered off (power plugs must be disconnected) it is
possible to indicate the faulty component by pressing the indicate CSS button.
No. Description
1 Indicate CSS button
