RX1330 M3 Upgrade and Maintenance Manual 325
No. Print Description
1 UFM Connector for optional USB Flash Module (UFM)
2 FRONTPANEL2 Front panel connector (front panel on QRL)
3 P30 PSU connector (redundant PSU only)
4 FRONTPANEL1 Front panel connector (front panel module)
5 PWR3 PSU connector for ODD (2.5-inch HDD configuration)
6 PC98 PSU connector (standard PSU only)
7 PWR2 Power connector for HDD backplane
8 PWR1 PSU connector 12V
9 FAN5 SYS Power connector for system fan 5
10 USB 3.0 FRONT Front USB connector
11 FAN4 SYS Power connector for system fan 4
12 FAN3 SYS Power connector for system fan 3
13 FAN2 SYS Power connector for system fan 2
14 FAN1 SYS Power connector for system fan 1
15 PWR4 PSU connector for ODD (3.5-inch HDD configuration)
16 FRONT VGA Connector for optional front VGA
17 I2C5 OOB (Out Of Band) connector for HDD backplane
18 SATA 6 DOM SATA connector for ODD or SATA DOM
19 SATA 5 DOM SATA connector for SATA DOM (preferred connector
for SATA DOM)
20 micro SD iRMC microSD card
21 SATA 1-4 SATA HDD connector
22 TPM Connector for optional TPM
