RX1330 M3 Upgrade and Maintenance Manual 297
System board and components
14.5.3 Replacing the SATA DOM
14.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 50
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
14.5.3.2 Replacing the SATA DOM
Ê Remove the defective SATA DOM as described in section "Removing the
SATA DOM" on page 296.
Ê Install the new SATA DOM as described in section "Installing the SATA
DOM" on page 294.
14.5.3.3 Concluding steps
Ê "Reassembling" on page 60
Ê "Connecting the power cord" on page 64
Ê "Switching on the server" on page 66
Ê "Resuming BitLocker functionality" on page 95
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
