296 Upgrade and Maintenance Manual RX1330 M3
System board and components
14.5.2 Removing the SATA DOM
14.5.2.1 Preliminary steps
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
14.5.2.2 Removing the SATA DOM
Figure 209: Removing the SATA DOM
Ê Firmly remove the SATA DOM out of its connector.
14.5.2.3 Concluding steps
Ê "Reassembling" on page 60
Ê "Connecting the power cord" on page 64
Ê "Switching on the server" on page 66
Ê "Resuming BitLocker functionality" on page 95
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
