220 Upgrade and Maintenance Manual RX1330 M3
Expansion cards and backup units
9.5.2.5 Concluding steps
Ê "Reassembling" on page 60
Ê "Connecting the power cord" on page 64
Ê "Switching on the server" on page 66
9.5.3 Replacing an FBU
V CAUTION!
● Dispose of used battery properly. Keep away from children.
● Do not throw flash backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
9.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 50
Ê "Shutting down the server" on page 53
Ê "Disconnecting the power cord" on page 54
Ê "Getting access to the component" on page 55
9.5.3.2 Removing the defective FBU
Ê Remove the FBU with the holder as described in section "Removing the FBU
with the holder" on page 218.
Ê Disconnect the FBU cable from the FBU as described in section
"Disconnecting the FBU cable from the FBU" on page 219.
Ê Remove the FBU from the holder as described in section "Removing the
FBU from the holder" on page 219.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
