122 Upgrade and Maintenance Manual RX1330 M3
6.4.1.3 Installing an FJBU
Figure 40: Installing an FJBU
Ê Push the FJBU into its bay as far as it will go until the locking latch snaps in
place.
V CAUTION!
Ensure that the FJBU properly engages in its bay and is locked in
position in order to prevent it from sliding out of the chassis during
transportation.
6.4.1.4 Concluding steps
Ê No steps needed.
I To execute auto shutdown after power fail, you should install the FJBU
management software. How to install and configure the FJBU
management software, please refer to the “Fujitsu Battery Unit" user
guide.
6.4.2 Removing the FJBU
Note for servers using CMA (Cable Management Arm)
Regarding of removing the FJBU, additional tasks are needed, due to an
interference between CMA stopper and the FJBU.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
